Floor Mounting Aluminium Profile Channel for LED Strip (2m)








Floor Mounting Aluminium Profile Channel for LED Strip (2m)
📏 Need longer runs of profile? Most of our LED Profiles you can simply butt together.
✂️ Need shorter lengths? Cut by yourself or add our cutting service (leave a note at checkout with required cutting lengths).
➕ Need extra end caps?
Extra end caps for ALU33 can be found in the profile accessories section.
- 21.4mm wide floor mounting LED profile
- Perfect to complete your flooring solution
- Thick 3mm Opal Diffuser To Resist Damage
- Suitable for LED strip lights up to 12mm wide
A 2m long, heavy duty aluminium LED strip mounting channel complete with an extra thick diffuser makes this profile perfect for use in flooring where it needs to withstand regular footfall. The flange ensures a neat finish.
The internal sizing is large enough to accept any of our LED strip range, allowing you to select a light output level and colour that suits your application.
Supplied complete with 3mm thick diffuser and end caps.
Measurements:
LED strip lights sold separately.
Get a Bespoke QuoteSupplied Complete With End Caps & Mounting Clips (where applicable)
Professional, Durable Finish
Includes Diffuser
Easy To Install
Managing Long Runs of LED Strip
Unfortunately as low voltage electricity passes through cables, voltage drop occurs which means that over longer runs the LED’s at the end of a run will be less bright that those at the beginning.
View DetailsPower Supplies For LED Strip - How To Choose
There are a number of choices when it comes to selecting the correct power supply for your LED strip lighting installation. Here's a basic overview to help you choose.
View DetailsUnderstanding Colour Binning And SDMC
SDCM is an acronym which stands for Standard Deviation Colour Matching. SDCM has the same meaning as a “MacAdam ellipse”.This defines a zone colour space within which the human eye cannot discern colour difference.
View DetailsInstalling LED Strip Lights - Single Colour
A reliable LED strip lighting system relies on two elements being correct – proper system design and correct installation. If corners are cut then the installation may well work for a while but premature failure or erratic performance is likely.
View DetailsUsing HaloLED Controls To Create A Smart Lighting System
HaloLED is a cost effective, room level, smart lighting system that allows you to easily control different types of led lighting from one place. Create scenes and zones, mix different types of LED Strip .
View DetailsRGB vs RGBW LED Strip
RGBW adds a real white LED to the standard red, green and blue chips to allow the creation of pastel colours and a dedicated white light when required - best of both worlds!
View DetailsWhat Makes A Good LED Strip?
It’s often difficult to tell the difference between top quality LED strip lighting and cheap imitations at a first glance. Wondering why the cost price can vary by a factor of 10 between suppliers? Read on..
View DetailsThe Benefits of Adjustable White LED Strip Lights
Tunable white LED strip light, adjustable colour temperature LED strip or CCT changeable LED tape lights are able to change between different temperatures of white light ranging from very cool white all the way down to very warm white and everything in-between.
View DetailsQUESTIONS & ANSWERS
Ask a Question-
Do you have 4 metre lengths ? And also do you have clear diffusers and not frosted ?
Hi, This product comes in a 2 metre length only, however two can be better together to make 4 metres, they only come with the frosted diffuser.
-
HI , THERE , GOOD AFTERNOON / MORNING , CAN THIS PROFILE AND DIFFUSER BE CUT TO A DESIRED LENGTH , PLUS THE INSIDE STRIP LIGHT , AS WELL . KIND REGARDS ALAN
Hi,
Yes, the Aluminium profile and diffuser can be cut to size aswell as the LED strip, just check what the cut points are on the LED strip. -
Is the led tape and floor mounting suitable for outside use ie to insert on a stone patio
Hi, the profile and diffuser are suitable for outdoor use but you'll have to make sure you use a waterproof LED strip with them and seal all of the connections well with silicone.
