TradeStrip Natural White LED Strip, 24V, 4000K, IP67
Overview
Natural White LED strip with 120 LEDs per metre for cabinet, plinth and accent lighting. Its extruded covering protects the strip against water splashes.
Ordering & connections
Order by the metre: quantity 1 = 1m. Supplied as one continuous selected length up to the listed 9m single-run limit.
Use soldered cable connections and the listed waterproof-strip soldering service.
Length with end caps: Sealed end caps add 20mm to the LED cut length in total. A 1,000mm LED strip therefore measures 1,020mm once both end caps are fitted. This allowance applies once to each completed section.
For a 1,000mm space, use a 950mm LED cut length. With sealed end caps, the finished strip measures 970mm. The strip has 50mm cut points, so allow for the end caps before choosing a cut length. The bathroom niche kit builder includes this allowance when calculating the finished length.
Cable for ALU34 niche kits: Use SPLASH12-2CORE 2-core cable for a soldered connection through the current ALU34 end caps. Choose the required cable length and add the appropriate waterproof-strip soldering and sealing service.
Installation & control
Use compatible single-colour 24V control and a suitable DC power supply.
Use the existing waterproof-strip service and installation guidance when preparing cut sections.
Apply the adhesive backing to a clean, dry mounting surface.
Specifications
- Operating voltage: 24V DC
- Power: 9W per metre
- White colour temperature: 4000K
- Cut points: 50mm
- Sealed end-cap allowance: 20mm total per completed section
- Maximum one-end-fed run: 9m
- LED density: 120 LEDs per metre
- Light output: 900 lumens per metre
- CRI: >80
- Adhesive backing: 3M VHB
- Strip IP rating: IP67
- Warranty: 5 years against failure
Accessories & downloads
Add some profile
Customer Reviews
All the items were good quality and for reasonable price. Would recommend those.
Bought it for a kitchen looks nice and bright , very good quality.
This self adhesive led ribbon is brilliant in all ways. The self adhesive tape is really sticky, to the point of making it difficult, but not impossible, to remove the backing tape. The lights themselves are very bright and, with the leds being close together, give an almost continuous light along the length. The only small problem I had was, having chosen to solder my feed wires on myself, I thought the copper contacts could be a bit bigger. I got the hang of it in the end, but I would probably look at using easy fittings, if there are such things.
They seem ok
great job, fast delivery
Follow and tag us at @LEDSpaceLighting
Product Q&A
-
What's the width of this strip? I'm having trouble to decide which profile to buy for this
Hi,
I can confirm that this strip is 10mm.
-
Can this product be cut to size?
H,
Cutting point on that strip is every 50mm. -
Hi. I wanna use this strip since it's IP RATED for zone 0 & 1 for above my shower inside the plaster-in profile. You mentioned to keep the ip rating on corners it has to be soldered using cable, do you literally mean butt the two led ends up at the corner, strip away enough ip rating plastic and solder pos+neg using cable? Thanks.
Hi, Yes this is how it is achieved, although you would not require to cut away any of the plastic as tghere are end caps used, we would always recommend that this is completed by us as this way the warrnaty is not affected,
-
Hi, Is this LED strip dimmable? If so, does it require a constant voltage or constant current driver? Thanks.
Hi Kevin, yes the strip is dimmable with the correct dimmable driver, the driver must be constant voltage.
