Splashproof 12V RGBW PixelStrip In Silicon Sleeve | 60 LED | UCS2904
metre(s)
Splashproof 12V RGBW PixelStrip In Silicon Sleeve | 60 LED | UCS2904
A 12v pixelstrip with 60 LED's per metre on a black PCB. Each addressable pixel is 3 LED's. Each lighting element is a pixel and the output is driven by patented PWM technology, which guarantees high colour consistency across all pixels. The control circuit consists of a signal shaping amplification circuit, a built-in constant current circuit, and a high precision RC oscillator.
The LED has a low drive voltage which allows for environmental protection and energy saving, high brightness, good consistency, low power, and long life.
The drive IC is the well proven UCS2904. It has a 3 line construction with +ve, data and -ve.
Reduce Spotting with an LED Profile Channel + Diffuser.
Fully Dimmable With The Correct Controls
Easy To Install
